Standard Hydraulic Power Units

This hydraulic power unit uses a standard range of modular components for easy specification, assembly and maintenance in the most demanding industrial applications. With motors up to 30 kW, flow rates to 100 litres/minute, tank capacities to 180 litres and pressure capability to 250 bar, we can offer a hydraulic power unit system to meet most industrial requirements including:

• Cranes
• Launch recovery systems
• Bailers and compactors
• Agricultural processing machinery
• Punching machines
• Injection moulding machines
• Lifting equipment
• Marine applications (test rigs, drilling rigs)

Unit options and specs

The hydraulic power unit components give an economic solution with the units catering for a selection of tanks ranging from 16-180 litres and pressures up to 250 bar, with flow rates of up to 100 litres/minute.

The AC motors within the units are all IP55 as standard and multi mount B35 configuration. Motor options such as Anti-condensation heaters and Ex protection are possible so please remember to enquire about these when you spec up your unit.

Wide range of applications covered

The standard power units are suitable for a wide range of applications; one of these being the marine based Launch Recovery System. This system is equipped with an umbilical winch which has to be able to accommodate the whole length and diameter of the remotely operated vehicle umbilical. The hydraulic power units power the hydraulic winch motor that, in turn, controls the winch itself which is responsible for pulling in the remotely operated vehicle (ROV).

Conforming to European standards

Power unit pumps are based on European standard 1:8 taper 4 bolt gear pumps from Groups 1,2 and 3. Low pulsation gears give a quiet and smooth flow. Group 2 and 3 pumps have cast iron flanges for extra strength.

All power units have 90 micron suction filters and 25 micron return filters as standard. Pressure filters to 3microns are optional and give our power units high cleanliness levels.

Hydraulic power unit suppliers offer a hydraulic circuit and parts list, we can also offer this as well as a full installation and maintenance manual. Each power unit is supplied with a test certificate and CE approval documentation.

Bespoke design options

Where the hydraulic power unit (HPU) does not offer all the hydraulic features required, we can design and manufacture a full hydraulic power unit system using our proven CAD design software and renowned technical expertise.

We hold a vast library of modular parts which can be used to populate 3D solid unit models making the customisation process easy and enables us to standardise designs, leading to a quick turnaround of customised units. This gives our end user a solid, dependable unit with the Hydraproducts stamp of approval.

For more information on the products please view our brochure located in our Technical Download Library, contact our team or chat to our online webchat facility.
